TH-UP64【FOB】High-resolution 3D UV Wall Printer Floor and Wall Printer Inkjet Parking Space Painting Machine
BAIKETECH TH-UP64 AI Intelligent Floor Printer : Quick, Easy, and Stunning! |
|
Integrating high inkjet technology, BAIKETECH's new AI intelligent UV wall printer has high effciency and high quality, to print true-to-ife and delicate patterns directly on various walls. It Brings you unprecedented wall decoration experience.
|
-10.jpeg?w=960&h=1024) |
 |
| Key Features |
|
1. Easy operations with fast speed, efficiently print in short time.
2. High-resolution 3D print result, so clear and realistic as reality. 3. UV Ink ensures colorful and attractive iamges, wear-resistant and prolonged perservation 4. Cost-effective model, with low comsuption of ink and low usage cost, no extramaintenance fee 5. Broad applications on multi surface medias and various scenarios, with substantial profit 6. Durable and stable control system, long service time and less after-sales problem 7. AI Intelligent Operating System: Automatically, independently, no need for external computer 8. Automatic Obstacle Avoidance for Print Heads:Automatically detects and avoids obstacles 9. Precise Color Management:Auto-calibrates colors using AI algorithms, high-quality printed results. 10. Ink Stock Management: Prevents ink depletion emergencies 11. Ultra-Long 10 Hours Battery Life 12. Customizable System Languages: English, Chinese, Russian, French, Arabic and more 13. Light weight: 35kg 14. High speed: 32 m2 per hour 15. Low cost: 120-200 m2 per ink group 16. H16 head for clear printing 17. High resolution: Up to 9600dpi 18. Easy for transportation 19. Detection function with 1mm accuracy 20. Easy operation with pre-installed software 21. Power failure recovery system |
 |
| Technical Parameters |
| Product Name | AI Intelligent Floor Printer |
| Print Head | Double Epson H16 |
| UV Ink | 5 colors: CMYK+W |
| Print Speed | Up to 64m2/h |
| Print Accuracy | Up to 9600dpi |
| Ink Consumption | 6-10ml/m2 |
| Ink Capacity | 400ml |
| Inkjet Distance | 0.5-2.0cm |
| X-axis Rail/Y-axis Rail/Y-axis Rail | 2300mm/free/1700mm |
| Machine Weight | 39KG |
| Machine Size | 40*50*254cm |
| Folded Size | 40*32*163cm |
| Power Supply | AC110V(90-132V)/AC220V(180-264V), 47-63HZ |
| Power Consumption | No load mode<20W, General mode<75W(up to 250W) |
| Noise | Standby mode<20dba, Printing mode<50dba |
| Battery Life | 10h |
| Operating Temperature | From -10°C to 60°C (-14°F-140°F), 10%-80% relative humidity, non-condensing. |
| Storage Temperature | From -30°C to 60°C (-22°F-140°F), 10%-80% relative humidity, non-condensing. |
| Data Transfer | USB2.0/3.0 |
| Mother Configuration | 6 cores CPU, 2GB DDR storage |
| Ultrasonic Sensor | 2 pcs |
| Nozzel Protection | Yes |
| Printing Orientation | Vertical |
| Touchscreen | 12-inch |
| Flash Jet Testing | Yes |
| Inkjet Testing | Yes |
| Obstacle Avoidance | Yes |
| Gradienter | Yes |
| White ink | Optional |
| Printing Gallery | Exquisite Printing Gallery Book + External Hard Drive |
| Image Processing | AI Intelligent Image Processing |
| Auto Partition of Large Image | Yes |
| Auto Interruption Marking | Yes |
| Auto Image Patching | Yes |
| Static Area Calibration | Yes |
| Step Calibration | Yes |
| Nozzle buffering | Yes |
| Ink Supply | Negative Pressure Automatic Ink Supply |
| Color Matching | Automatic Color Matching |
| Coloring Medium | All White Walls |
| Integrated voltage regulator | Yes |
| Laser Positioning | Yes |
| Magnetic Sensing Limit | Yes |
| Auto White-skipping | Yes |
| Lithium Battery | Yes |
| Computer system | WindowsXP/Win7/Win8/Win10 |
| Certification | CE Certificate, compliant with national standards (GB18582-2001, GBT9756-2001) |
| Product Analysis |
| BAlKETECH wall printer has strong capability to print any image on walls: cement, tile,brick and even metal, glass etc. in just minutes, the HD image is printed by UV ink,ensuring clear, realistic and wear-resistant 3D effect and greatly improving the productivity. Supported by powerful hardware and software, it can work steadily for many years,and realize one-click to print intelligently, as a veritable hand-free solution for modern enterprises. For commercial advertising and personal art decoration, it's the absolute unique choice. |
 |
|
AI Operating system Independently developed software and hardware, no need for external computer |
 |
|
5G Wireless operation Separation of man and machine, shackles of shielded wires. |
 |
|
EPSON industrial print head |
-4.jpeg?w=960&h=540) |
|
Double H16 1. Equipped with epson professional print heads |
-9.jpeg?w=960&h=515) |
|
Color Management System 1. Automatically calibrates printing colors using Al Algorithms |
-7.jpeg?w=960&h=498) |
|
Ink management system 1. Real-Time Monitoring of ink Levels |
 |
|
Customized language 1. Touch screen response speed is fast |
 |
|
10-hour battery life 1. Ultra-Long 10-Hour Battery Life |
-3.jpeg?w=960&h=503) |
|
64 m2/h high-speed printing 1. High-speed Data Transmission |
 |
|
9600 DPI 1. Professional lmage Processing |
| New Printing Technology |
 |
|
Standard printing When the image height is less than 2 meters (standard height is 2 meters) and thelength can be extended indefinitely, the Baike Al intelligent Printer can create a per-fect image in one go, without the need for partitioning or block printing. |
 |
|
Large image partition When the image height exceeds 2 meters and the length can be extended indefinitely, the Baike Al inteligentPrinter can automatically divide the large image into Nsmall images for printing. During printing, the N smallimages can be automaticallyseamlessly connected to form a complete large image. |
 |
|
Intelligent printing When printing, the Baike AI smart printer can intelligently recognize the white areasin the image, automatically skip the white areas, and seamlessly connect thenon-white areas for printing, this innovative technology can save ink, shorten print-ing time, and is suitable for printing on white walls. |
 |
|
Printing interruption If printing is paused or interrupted, the Baike Al intelligent Print-er can automati-.cally mark with a "+", When resuming printing. align the machine's red crosshair("+") with the wall's mark "+"and the system will automatically align and resumeprintingseamlessly,preserving the complete image. |
 |
| Application |
 |
 |
|
Wide application ranges It can be painted on epoxy floors, tile floors, glass floors, metal floorspaint floors, rubber floors,carpet floors, wooden floors, cement floors,asphalt floors and other floors.It has a wide range of applications and unlimited market potential. |
| Company Profile |
|
Wuhan Baike Times Laser Technology Co., Ltd. was founded in 2014 as a professional supplier of laser machine, located in Optical Valley of China, has gathered the best R&D, production and marketing teams in the domestic laser industry. More than 100 kinds of industrial laser products, including pneumatic marking machine, laser marking machine, laser welding machine, laser cutting machine, developed by the company's technical team, have been widely used in 3C electronics, semi conductor, new energy (including photovoltaic), metal processing, automobile manufacturing, electric power, textile machinery, fashion FMCG, medical devices, instruments and meters, food processing and other industries. The product quality and service have been highly praised by customers internationally. We have achieved strategic cooperation with dozens of domestic top 500 manufacturing enterprises. We've been dedicated to provide our customers with the highest quality, the best cost performance, the most suitable laser equipment. lf you have any needs, please call/mail us directly. All you need to do is just tell uswhat you need, wel provide the most professional services. |
| FAQs |
| Q1: Are you a factory or a trading company? |
| Answer: We are a factory. Our company was established in 2014, and our factory is located in Wuhan, Hubei, China. You are welcome to visit us anytime. |
| Q2: How long is the warranty period after purchasing the machine? |
| Answer: Our machines come with a free one-year warranty, as long as the damage is not caused by human factors. |
| Q3: How soon can the delivery be made after payment? |
| Answer: After payment, we will ship the machine within 7-14 days. |
| Q4: How long can the printed patterns remain on the wall? |
| Answer: The printed patterns can last for up to five years outdoors and about ten years indoors. |
| Q5: How much ink is consumed for printing patterns? |
| Answer: Approximately 500ml (one bottle) of ink can print around 100 square meters, while 500ml of white ink can print approximately 50 square meters. |
| Q6: What should I do if I no longer want the printed pattern on the wall? |
| Answer: You have a couple of options. One option is to directly cover the unwanted pattern with white ink and then replace it with a new design. Alternatively, you can cover the wall with a suitable material based on its original surface. For example, if it's a latex paint wall, you can use latex paint to cover and overwrite the existing pattern. |
| Q7: What language settings are available on the machine? |
| Answer: Typically, the machine supports English and Chinese. If you require other languages, we provide free translation services. |
| Q8: How do you handle uneven ground during printing? |
| Answer: The machine is equipped with adjustable feet that allow you to adjust the track according to the unevenness of the ground. This ensures stable and precise printing even on uneven surfaces. |
| Q9: How is the quality of the machine? Are there any components that are prone to damage? |
| Answer: Our machines have excellent quality, and each machine undergoes comprehensive quality inspection before leaving the factory. The print head is a component that may be more susceptible to issues. We recommend having spare print heads on hand in case of any malfunction. |
| Q10: Can one print head be used for printing four colors, while another print head is dedicated to printing white? |
| Answer: Yes, our machine can be configured to have one print head for printing four colors and another print head dedicated to printing white. This allows for efficient and precise printing of both color and white elements in your designs. |
