MFSC-1500X【FOB】MAX CW Fiber Lasers
MAX MFSC-1500X 1500W Single Mode CW Fiber Laser Source Power for Laser Cutting Machine |
|
1000W~6000W SINGLE MODULE CW FIBER LASER is a high-power fiber laser with high electro-optical conversion efficiency, compact size, good beam quality and maintenance-free. Wide fiber core diameter range from 100~600um, can be customized from 800um~1000um. Mainly used in metal welding and cladding and other fields such as new energy, 3C, precision machining.
|
| Key Features |
|
1. Modular design, stable performance |
| Technical Parameters |
|
Model
|
MFSC-1500W
|
MFSC-2000X
|
MFSC-3000C
|
MFSC-4000X
|
MFSC-6000C
|
MFSC-6000M
|
|
Optical characteristics
|
||||||
|
Output power (W)
|
1500
|
2000
|
3000
|
4000
|
6000
|
6000
|
| Mode of operation |
Continuous / Pulse
|
|||||
|
Polarization state
|
Random
|
|||||
|
Power adjustment range (%)
|
10~100
|
|||||
|
Center wavelength (nm)
|
1080±10
|
|||||
|
Spectral bandwidth 3dB (nm)
|
3~5
|
|||||
|
Power stability (%)
|
±1
|
|||||
|
Beam quality M²
|
3.1 to 3.5 mm x mrad (100μmQBH)
|
|||||
|
6.4 to 7 mm x mrad (200μmQBH)
|
||||||
|
10 to 12 mm x mrad (300μmQBH)
|
||||||
|
15 to 17 mm x mrad (400μmQBH)
|
||||||
|
25 to 28 mm x mrad (600μmQBH)
|
||||||
|
Modulation frequency (KHz)
|
≤5
|
|||||
|
Indicator red light power (μW)
|
200 μW
|
|||||
|
Output optical cable parameters
|
||||||
|
Output mode
|
Standard QBH(LOC)
|
|||||
|
Fiber optic cable length (m)
|
15(Optional)
|
|||||
|
Diameter(μm)
|
100/200/300/400/600
|
|||||
|
Fiber optic cable bending radius (mm)
|
200
|
|||||
|
Electrical parameters
|
||||||
|
Working voltage (VAC)
|
Single-phase 220
|
|||||
|
Other parameters
|
||||||
|
Working environment temperature (℃)
|
10~40
|
|||||
|
Storage temperature (℃)
|
-10~60
|
|||||
|
Working environment relative humidity (%)
|
10~85
|
|||||
|
Cooling method
|
Water Cooling
|
|||||
|
Complete machine size (mm)
|
800×482×193
|
483×950×193
|
483×950×193
|
640×1173×1102
|
640×1173×1102
|
640×1173×1102
|
|
Complete machine weight (kg)
|
55(±3)
|
72(±3)
|
72(±3)
|
200(±20)
|
200(±20)
|
240(±20)
|
| Application |
| Raycus Laser sources are widely used in multiple industries. such as maunfacturing industry, Automative industry , Aerospace, Petrochemical Industry, Rail Traffic, 3C Electrinic , Sheet metal working , Advertising Sign, Kitchen industry, Househeld appliance, fitness equipment, precision Machinery,etc. |
| Package |
In order protect your machine well, we pack the goods by thick wooden box.
