TH-2004S-3000W【FOB】Small-format High Precision Laser Cutting Machine
|
FLAT PLATE CUTTING MACHINE The small flat plate fiber laser cutting machine is a highly efficient, precise and cost-effective integrated cutting and hole cutting machine. Its cutting accuracy and speed are both higher than those of the ordinary standard flat plate laser cutting machine. It is mainly suitable for small and precise cutting, featuring all the advantages and functions of unique flat plate cutting. With an integrated design that serves two purposes in one, it can process both plates and pipe fittings. Customizable installation fixtures and clamps can be used to fix short pipe fittings, enabling drilling and cutting of various small pipe fittings. |
 |
|
1.The gantry moving platform structure and the plate and tube welded bed ensure the stability of long-term operation. |
| Technical Parameters |
| Techincal Specifications | |
| Model name | High precision small-format laser cutting machine |
| Laser Power | 1000W/1500W/2000W/3000W/6000W |
| Working area | 2000mm×600mm |
| Length of X-axis | 600mm |
| Length of Y-axis | 2000mm |
| Length of Z-axis | 200mm |
| Max cutting thickness | Carbon Steel: 12mm |
| Stainless Steel: 6mm | |
| Aluminum: 3mm | |
| Minimum cutting aperture | 3mm |
| Maximum rapid traverse speed | 50m/min |
| Cutting path accuracy | 0.05mm |
| Repeatability accuracy | 0.03mm |
| Power supply | Three-phase five-wire system, AC380V/50Hz |
| Overall power consumption | ≤15kw |
| Main power supply protection rating | IP54 |
| Equipment footprint | 4.5 m² |
| Main Configuaration | |||
| Name | Unit | Quatity | Brand |
| Laser source | set | 1 | Raycus |
| Laser cutting head | set | 1 | WSX |
| Water cooler | set | 1 | Hanli |
| PLC system | set | 1 | BAIKETECH |
| AC servo motor | set | 4 | Inovance |
| Ball Screw | piece | 3 | TBI |
| Linear Guide | piece | 3 | Hiwin |
| Product Introduction |
| It is mainly used for high-speed cutting and punching of various thin metal sheets and small pipe fittings, especially suitable for stainless steel, aluminized zinc plates, silicon steel, alloy steel, copper, square tubes, round tubes and other metal materials. It is widely applied in various thin metal sheet metal processing, kitchen and bathroom, panel processing, auto parts, handicrafts, hardware products and other metalprocessing industries. |
| Cutting head 1.It adopts a uniquely designed blowing method to reduce the contamination of the internal lenses during cutting. 2.The optical focusing lens group is made of imported materials, ensuring a long service life of the lenses. 3.The focusing part of the cutting head is drilled with a hexagonal wrench, and the interior adopts a professional focusing design, ensuring a stable optical focus. |
Machine tool 1.The moving parts adopt high-precision lead screws and linear guides, as well as servo motors. Smooth transmission, high speed and high precision. 2.The machine tool as a whole adopts a mobile platform structure. It has good rigidity, high precision, does not deform during use and has good stability. |
| Laser source It adopts domestic first-line brand fiber lasers with strong anti-reflection performance. It has strong reliability and a long service life, effectively ensuring long-term stable operation. |
Control cabinet This control cabinet adopts an integrated control cabinet design, featuring independent control of various components such as the industrial computer, drive shaft, laser, water cooler and follower, to facilitate operation and maintenance. |
| Numerical control system 1.Supports input of multiple file formats such as DXF, DWG, and IGES, batch import of parts, and import of CSV part lists. 2.The cutting path is automatically optimized, with an independent process database, and it also supports common edge cutting. 3.Professional CAM interface, fully meeting the display requirements of various processes. |
Water cooler Provides cooling circulation for lasers and constant-temperature cooling for laser cutting heads. It is efficient and environmentally friendly, equipped with water flow and overtemperature alarms, as well as laser linkage signal protection. |
| Application |
| The small flat fiber laser cutting machine is economical and practical, takes up less space, is easy to use, and is very convenient to move and place. With brand-new technological solutions, we have solved the pain points of low return on investment and high equipment maintenance costs for growth-oriented customers, effectively enhancing processing efficiency. The operation is simple and convenient, making it highly suitable for teaching and experimental research. Customization can be made according to customer needs. |
| More Choices for Customization |
 |
|
