TH-HW1500D【FOB】3 in 1 Handheld Laser Welding Machine

Baiketech Portable Handheld Raycus 1500W 2000W 3000W Fiber Laser Welding Machine Built for High-quality Welding

Baiketech Water Cooling Handheld Raycus Fiber Laser Welder Machine for Welding Metal Stainless Steel Aluminum

Home / TH-HW1500T BWT【FOB】3 in 1 Handheld Laser Welding Machine

TH-HW1500T BWT【FOB】3 in 1 Handheld Laser Welding Machine

Name: TH-HW1500T BWT【FOB】3 in 1 Handheld Laser Welding Machine
Brand: BAIKETECH
SKU: TH-HW1500T
Price: 2599 USD
Availability: InStock

1. Ergonomic Design , Easy to Move and Transport 2. Compact Structure, Easy to Operate and Maintenance 3. Light and Flexible Handheld Welding Head 4. It can Welding at any angles 5. Integrated gas protection system and auto feeder 6. Built-in Water Chiller 7. Rated output power: 1500W/2000W(for choice)

$2,599.00 USD $2,899.00 USD

Global Sales Of More Than 500 Products

1-3 Years Long Warranty

Products Has Passed Quality Certification

100% Inspected Before Delivery

Power

Quantity

Description

Baiketech 1500W/2000W Water Cooling Handheld Fiber Laser Welding Machine

Key Features:

Widely used in precision machining, 3D printing, sheet metal processing, lithium-ion battery processing and other fields.
Fiber lasers have higher photoelectric conversion efficiency, lower power consumption, and higher beam quality compared to traditional lasers.
Fiber laser has a compact structure and can be used at any time. Due to its flexible laser output mode, it can be easily integrated with system equipment.
With better beam quality, the laser beam can be focused close to the diffraction limit, achieving precision machining
There are two working modes to choose from: continuous and modulated pulse, which can greatly reduce the processing heat affected zone

Welcome to visit to our factory at any time!

Application:

Baiketech Laser welding machine can be applied to weld stainless steel, carbon steel, aluminum alloys, etc
Baiketech Laser welding machine can weld at any angles: butt welding ,lap welding, stack welding,nail welding,crimp welding ,T-type welding ,Overlap welding,edge Welding , etc.

Parameters of Machine:

Model Number	TH-HW1500D		TH-HW2000D
Voltage & Frequency	AC 220V~240V 50hz	AC 220V~240V 60hz	AC 220V~240V 50hz	AC 220V~240V 60hz
Current	0.9-9.8A	0.9-7.7A	0.91-13.61A	0.91-12.81A
Machine power	1.59 KW	1.56 KW	2.31 KW	2.34KW
Cooling capacity	3700W	4100W	5574W	6140W
Tempe. control accuracy	±1℃
Application environment	0℃<Environment temperature<45℃, Ralative humidity <95%
Electric heating power	500W
Refrigerant	R410a
Rated flow of water pump	>2m³/h
Max. pump lift	40M		40M
Tank volume	16L
Rated output power	1500W		2000W
Laser nozzle interface	G1/2* φ12mm Quick connector		G1/2* φ20mm Pagoda connector
QBH head nozzle interface	G1/2*φ6mm Quick connector
Machine weight	121KG		132KG
Machine size	910mm490mm690mm（ LWH ）		1080mm490mm690mm（ LWH ）
Functional characteristics	environmental protectiom.double temperature controls,flow & over temperature,Compressor overheat protection

Machine Introduction:

	1. Thick Sheet metal cabinet integrated design, Mutilfunctional protection, Anti-corrosion and anti-rust
2. Raycus Brand Laser Good Beam quality High power output High energy density
	3.New Laser Welding Gun Built-in dual drive and dual swing Has 6 light spot modes Good welding effect Light weight :0.8kg
4.Hanli Refrigeration System 24-hours Non-stop work intelligent control, adaptive hot and cold dual temperature adjustment Stable performance,safe, dustproof and anti-condensation Suitable for various working conditions and sites

	5. New Geneeration wire feeder 0.8-1.6mm welding wire Automatic wire feeding Extract freely Welding more efficient
6.Intelligent Control Panel Full touch screen Self-developed system Real time monitoring Alarm protection Intelligent operation Safe and stable
	7.Laser Cleaning Head Continuously working No burning of Lenses Flexible operation Clean irregular workpieces Adjustable cleaning width
8.Other Components 10m Fiber optic cable High quality switch Standardized wiring 360° universal pulley

Our Advantanges:

Welding is smoothe, Finished at oncce
Easy to get started for beginner
Welding speed is fast, increase efficency 4-6times
Low calorie, high safety, just wear goggles

Packing and Delivery:

About US:

Baike intelligent Technology Co., Ltd was established in 2014 and it headquartered in Wuhan, China. Over the past 10 years, we have the best R&D, production and marketing teams in the laser industry, and have successfully developed more than 500 laser products, which are exported to more than 180 countries. Our product footprints are spread across all walks of life around the world, and our product quality and services have been 100% praised. Baike is committed to providing innovative industrial laser solutions to customers around the world！
Welcome to visit our factory at any time in Wuhan City, China!

FAQs:

Q1: Are you a factory or a trading company?
Answer: We are a factory. Our company was established in 2014, and our factory is located in Wuhan, Hubei, China. You are welcome to visit us anytime.

Q2: How long is the warranty period after purchasing the machine?
Answer: Our machines come with a free one-year warranty, as long as the damage is not caused by human factors. (Optical lenses, welding nozzles, etc. are consumables and are not covered by the warranty.)

Q3: How soon can the delivery be made after payment?
Answer: After payment, we will ship the machine within 7-14 days.

Q4: What language settings are available on the machine?
Answer: Multilingual，Such as English ,French, German,Polish,Spanish ,etc.

Q5: There is a water cooler in the welder, Can it be filled with tap water ?
Answer:The best way is to use purifed water and distilled water for the machine. As we know that if the tap water have some impurity inside, the machine can not get good environment water for cooling. If long time do it like this way, the machine laser source and welding head life time will be shortly than using purified water or distilled water.If the water is not purified, the welding head and laser source easy broken. Because impurity have some unknown materials.

Q6: How is the quality of the machine? Which accessories are consumables?
Answer: Our machines have excellent quality, and each machine undergoes comprehensive quality inspection before leaving the factory. Nozzles and protective lenses are easily consumable. We recommend having spare ones on hand in case of any malfunction.
